The Lincoln Square Wave TIG 200

The Lincoln Square Wave TIG 200
Affordable and Powerful TIG Welding with the Lincoln Squarewave TIG 200 Welder

TIG welders will benefit from the flexibility and variety of features available in the lightweight and versatile Squarewave TIG 200 welder from Lincoln Electric. Take this machine anywhere and weld a wide variety of materials, swapping TIG or stick welding settings in order to work with steel (up to ⅜”), stainless steel, aluminum (up to 3/16”) and chrome-moly.

This entry-level TIG machine is affordable, priced at $2,399 with a free TIG consumable kit and a $400 rebate through Lincoln Electric! Let us know if you have any questions.

Comparing the Squarewave TIG 200 to Other TIG Machines

From pulsing options to its hefty 200 amps total rated power, the Squarewave provides a much-needed balance of power and affordability in the TIG welding market. Some of the larger TIG machines from Miller or Lincoln can range anywhere from $5,000 to $10,000, while the smaller “suitcase” TIG welders from ESAB hover around $500. However, these larger welders may offer more power than many welders require, and suitcase welders may not have the power to deliver on routine welding projects.

This is why the SquareWave shines as an extremely affordable machine that doesn’t sacrifice its power, functionality, or features.

Versatile Welding Options

Swap out DC or AC power or use 120V vs 230V power on this versatile TIG welder that can also switch to stick welding for thicker metal or outdoor projects where shielding gas may not be effective. Crank up the power to 200 amps when you need it, but also weld thin metals without distortion or burn-through.

Better Settings for TIG Welding Aluminum

Switching from DC to AC power makes it possible to TIG weld aluminum with the Lincoln Squarewave TIG 200. When TIG welding thinner metals like aluminum, welders will get started faster with high frequency starts and benefit from adjust their arc for wider or tighter configurations depending on the weld size and position.

By using the Squarewave for aluminum projects, welders will have cleaner, stronger welds because of the variety of settings and cleaning options available. Welders can also pulse at 0.5-2.0 pulses per second, minimizing the material distortion and  giving more control over the amount of material added to the weld.

Get Better Value Today with the Lincoln Squarewave TIG 200

Read customer reviews, watch expert video reviews, or add on the perfect accessories or safety gear for the Squarewave TIG 200 now at Baker’s Gas and Welding. With the promo code TIG200 and Baker’s free ground shipping, you’ll find one of the best deals online for this industry-leading TIG welding machine, while also saving big on any add-on items.

  • TIG welding for critical welds where precision and bead

appearance are important.

    • Bonus of stick welding capability for outdoor work or thicker materials.

    Take it Everywhere, Plug in Anywhere.™

    • Plugs into a standard 120V or 230V circuit.
    • Portable and convenient to use – only 46 lb (21 kg).

     Pulser: 0-20 Pulses per second (default = off)

    • Alternating peak and background current controls heat input.
    • Minimize material distortion

    TIP: Lower pulse frequency provides a reference for adding filler metal,

    making you a better TIG welder faster.

    (pulsing: 0.5 - 2.0 pulses per second)

    The Square Wave TIG 200 is a portable TIG and Stick welding machine that lets hobbyists, makers, small fabricators, and craftsmen explore their creativity.

    The Square Wave TIG 200 provides smooth and stable AC TIG welding on aluminum and DC TIG welding on steel, stainless steel and chrome-moly. The user-friendly interface enables the operators to set it, forget it and weld. This machine has advanced features, yet is easy to use with the simple user interface and pulse feature. Square Wave will TIG weld up to 3/16" Aluminum or 3/8" Steel.


    Simple user interface makes machine setup easy

    Pulse mode helps make you a better TIG welder, faster

    Portable - weighs only 46 lbs.

    Plugs into a standard 120V or 230V circuit

    LED display with indicator lights

    Output Range: 120V Tig (10-125A), Stick (10-110A)

    Output Range: 230V Tig (10-200A), Stick (10-170A)

    Rated Output: 230V Tig (200A @ 25%), (130A @ 60%)

    Pulse: 0.1-20 (Pulses Per Second)


    High frequency start for aluminum welding

    Allows adjustments for wider or tighter arc configurations

    Built-in settings for more cleaning action


    TIG welding for critical welds where precision and bead appearance are important

    Bonus of stick welding capability for outdoor work or thicker materials

    Ed Cyzewski
